350Cd/m2 High Brightness LCD Display 10 Inch LCD Screen
| Place of Origin | Shenzhen |
|---|---|
| 브랜드 이름 | DYMONA |
| Model Number | M101X60-156-0601 |
무료샘플과 쿠폰을 위해 나와 연락하세요.
왓츠앱:0086 18588475571
위챗: 0086 18588475571
스카이프: sales10@aixton.com
만약 당신이 어떠한 관심도 가지면, 우리가 24 시간 온라인 도움말을 제공합니다.
x제품 상세 정보
| 디스플레이 형태 | IPS | 공급자 타입 | 중국 공장은 직접적으로 공급합니다 |
|---|---|---|---|
| 시야 각도 | 85/85/85/85 (Typ.)(CR≥10) | 디스플레이 영역 | 216.96(W)×135.6(H) 밀리미터 |
| 픽셀 포맷 | RGB 세로 스트라이프 | 터치 패널 | 어떤 것도 패널을 접촉하지 않습니다 |
| 밝기 | 350 cd/m2 (Typ.) | 전원 공급기 | 3.3V |
| 하이 라이트 | 350Cd/M2 High Brightness LCD Display,350Cd/M2 10 Inch LCD Screen,High Brightness LCD Display 10Inch |
||
제품 설명
High Brightness LCD Display with RGB Vertical Stripe Pixel Format and No Touch Panel
Product Description:
This 10.1 inch LCD Display is a high brightness and strong performance display with a pixel format of RGB Vertical Stripe, a display Type of IPS, and a brightness of 350 Cd/m² (Typ.). It has a wide viewing angle of 85/85/85/85 (Typ.)(CR≥10) and no touch panel. The 500 nits display offers an excellent viewing experience for any application. The TFT LCD display is perfect for industrial applications such as medical, automotive, surveillance, and consumer applications. The display is designed to be low in power consumption and provide high performance with excellent clarity. The 10.1 inch display is ideal for any application that requires high brightness and a wide viewing angle.
Features:
- Product Name: 10.1 Inch LCD Display
- Operating Temperature: -20~70℃
- Contrast Ratio: 800:1
- Display mode: IPS, Normally Black, Transmissive
- Brightness: 350 Cd/m² (Typ.)
- Power Supply: 3.3V
- High-resolution IPS TFT LCD Display
- Custom TFT LCD Display with 10.1 inch size
- Robust TFT LCD Display with Wide Operating Temperature
- High Contrast Ratio and Brightness
- Low Power Consumption with 3.3V Power Supply
Applications:
DYMONA 10.1 Inch LCD Screen, with model number M101X60-156-0601, is a TFT LCD display which is manufactured in Shenzhen. It has a power consumption of 10W and an input interface of LVDS 40pin. The response time is 25 (Typ.)(Tr+Td) Ms, brightness is 350 Cd/m² (Typ.), and the display area is 216.96(W)×135.6(H) Mm. It is an ideal choice for applications requiring a reliable, high performance 10.1 inch LCD panel for a wide range of consumer, automotive, and industrial applications.
Customization:
10.1 Inch LCD Display
- Brand Name: DYMONA
- Model Number: M101X60-156-0601
- Place of Origin: Shenzhen
- Supplier Type: China Factory Directly Supply
- Light Source Type: WLED [3S11P] , 30K Hours , W/O Driver
- Operating Temperature: -20~70℃
- Power Consumption: 10W
- Contrast Ratio: 800:1
Color LCD Display Module - Our 10.1 Inch LCD Display is a high brightness LCD display with the model number M101X60-156-0601. It is manufactured with direct supply from our factory in Shenzhen. It is powered by WLED [3S11P] with a 30K hour lifespan and without driver. It has a wide operating temperature range of -20~70℃ and a power consumption of 10W. It also has a contrast ratio of 800:1.
Support and Services:
Technical support and service for 10.1 Inch LCD Display:
- 24/7 customer service and technical support
- Free product consultation and advice
- Regular product updates and patches
- Warranty and repair services
- On-site installation and maintenance
- Product training and tutorials
Packing and Shipping:
Packaging and Shipping for 10.1 Inch LCD Display:
- The 10.1 Inch LCD Display will be packaged in a static-free bag, surrounded by foam inserts.
- The package will be covered in bubble wrap and placed in a cardboard box.
- The box will be sealed and labeled with the product name, weight, and shipping address.
- The package will be shipped via courier service.
FAQ:
- Q: What is the Brand Name of this 10.1 inch LCD Display?
A: The Brand Name of this 10.1 inch LCD Display is DYMONA. - Q: What is the Model Number of this 10.1 inch LCD Display?
A: The Model Number of this 10.1 inch LCD Display is M101X60-156-0601. - Q: Where is this 10.1 inch LCD Display manufactured?
A: This 10.1 inch LCD Display is manufactured in Shenzhen. - Q: What is the display size of this 10.1 inch LCD Display?
A: This 10.1 inch LCD Display has a display size of 10.1 inches. - Q: What type of display is this 10.1 inch LCD Display?
A: This 10.1 inch LCD Display is a Liquid Crystal Display (LCD).
